Dell PowerEdge T350 Tower Server

The Dell EMC PowerEdge T350 addresses evolving compute demands with an easy-to-manage tower server designed for businesses looking for affordable enterprise features and it’s supports PCIe Gen4

Your Innovation Engine for businesses of all sizes

The Dell EMC PowerEdge T350, powered by Intel Xeon E-2300 processors, delivers increased performance and is designed for productivity and data-intensive applications.

It supports 3200 MT/s DDR4 speeds and 32 GB UDIMMs, up to 128 GB for memory-intensive workloads.

In addition, to address substantial throughput improvements, the PowerEdge T350 supports PCIe Gen 4 and offers enhanced thermal efficiency to support increasing power and thermal requirements.

With a smaller chassis design that reduces the size by 37% without losing any features or performance, the PowerEdge T350 is ideal for use inside or outside the data center.

The PowerEdge T350 addresses business critical workloads including database management, as well as cloud infrastructure needs and point of sale transactions.

Dell PowerEdge T350 Tower Server Increase efficiency and accelerate operations with autonomous compute infrastructure

The Dell EMC OpenManage systems management portfolio tames the complexity of managing and securing IT infrastructure.

Using Dell Technologies’ intuitive end-to-end tools, IT can deliver a secure, integrated experience by reducing process and information silos in order to focus on growing the business.

The Dell EMC OpenManage portfolio is the key to your innovation engine, unlocking the tools and automation that help you scale, manage, and protect your technology environment.

• Built-in telemetry streaming, thermal management, and RESTful API with Redfish offer streamlined visibility and control for better server management
• Intelligent automation lets you enable cooperation between human actions and system capabilities for added productivity
• Integrated change management capabilities for update planning and seamless, zero-touch configuration and implementation
• Full-stack management integration with Microsoft, VMware, ServiceNow, Ansible and many other tools

Protect your data assets and infrastructure with proactive resilience

The Dell EMC PowerEdge T350 server is designed with a cyber-resilient architecture, integrating security deeply into every phase in the lifecycle, from design to retirement.

• Operate your workloads on a secure platform anchored by cryptographically trusted booting and silicon root of trust
• Maintain server firmware safety with digitally signed firmware packages
• Prevent unauthorized configuration or firmware change with system lockdown
• Securely and quickly wipe all data from storage media, including hard drives, SSDs, and system memory with System Erase
• UEFI Secure Boot prevents systems from booting from unsigned or unauthorized pre-boot device firmware, applications, and OS boot loaders, protecting systems from malware corrupting the startup process

Dell PowerEdge T350 Tower Server Specifications

Processor : One Intel Xeon E-2300 Series processor with up to 8 cores, or Intel Pentium processors with up to 2 cores
Memory : 4 DDR4 DIMM slots, supports UDIMM 128 GB max, speeds up to 3200 MT/s , Supports registered ECC DDR4 DIMMs only
Storage :

• Internal Controllers (RAID): PERC H755, PERC H355, PERC H345, HBA355i, S150
• Internal Boot: Internal Dual SD Module or Boot Optimized Storage Subsystem (BOSS-S2): HWRAID 2 x M.2 SSDs or internal USB 3.0
• External PERC (RAID): N/A
• External HBAs (non-RAID): HBA355e

Front bays : Up to 4 x 3.5-inch SAS/SATA (HDD/SSD) max 64 TB , Up tp 8 x 3.5-inch SAS/SATA (HDD/SSD) max 128 TB

Power Supplies :

• 450 W Bronze (cabled) AC/100 – 240 V
• 600 W Platinum AC/100 – 240 V
• 600 W DC/240 V

Dell PowerEdge T350 Tower Server Cooling Options : Air cooling

Fans : System fan , one non hot swap fan

Dell PowerEdge T350 Tower Server Height : 382.5 mm (15.06 inches)

Width : 175 mm (6.89 inches)

Depth : 581.12 mm (22.88 inches) with bezel

Form Factor : 4.5U tower server

Embedded Management :

• iDRAC9
• iDRAC Direct
• iDRAC RESTful with Redfish
• iDRAC Service Module

Bezel : Optional security bezel

OpenManage Software :

• OpenManage Enterprise
• OpenManage Power Manager plugin
• OpenManage SupportAssist plugin
• OpenManage Update Manager plugin

Dell PowerEdge T350 Tower Server Mobility OpenManage : Mobile

OpenManage Integrations :

• BMC Truesight
• Microsoft System Center
• Red Hat Ansible Modules
• VMware vCenter and vRealize Operations Manager

OpenManage Connections :

• IBM Tivoli Netcool/OMNIbus
• IBM Tivoli Network Manager IP Edition
• Micro Focus Operations Manager
• Nagios Core
• Nagios XI

Dell PowerEdge T350 Tower Server Security :

• Cryptographically signed firmware
• Secure Boot
• Secure Erase
• Silicon Root of Trust
• System Lockdown (requires iDRAC9 Enterprise or Datacenter)
• TPM 1.2/2.0 FIPS, CC-TCG certified, TPM 2.0 China NationZ

Embedded NIC : 2 x 1 GbE LOM

GPU Options : Not supported

Front Ports : 1 x Dedicated iDRAC (Micro-AB USB) port , 1 x USB 3.0

Rear Ports :

• 5 x USB 2.0
• 1 x iDRAC dedicated port
• 1 x USB 3.0
• 1 x VGA
• 1 x Serial

Internal Ports : 1 x USB 3.0 (optional)

Dell PowerEdge T350 Tower Server PCIe : 2 x Gen 4 PCIe slots and 2 x Gen 3 PCIe slot

Operating System and Hypervisors :

• Canonical Ubuntu Server LTS
• Citrix Hypervisor
• Microsoft Windows Server with Hyper-V
• Red Hat Enterprise Linux
• SUSE Linux Enterprise Server
