Hikvision DS-D5B86RB/D 86″ 4K Interactive Flat Panel Display with Camera, 20px Ultra Fine Writing, Built-in Wi-Fi, 2/4 Split Screen, 2x 3W Speakers, USB-C, USB-A / RJ45, Free VESA Mount | DS-D5B86RB-D

Description for Hikvision DS-D5B86RB/D 86″ 4K Interactive Flat Panel Display with Camera, 20px Ultra Fine Writing, Built-in Wi-Fi, 2/4 Split Screen, 2x 3W Speakers, USB-C, USB-A / RJ45, Free VESA Mount | DS-D5B86RB-D

86-inch 4K Interactive Flat Panel
Ultra HD display with up to 3840 × 2160 resolution of input signal available.
20px ultra-fine writing, and 2 mm diameter recognizable with the precision of 1 mm.
Built-in Wi-Fi realizes miracasting without any cable connection.
Built-in interactive whiteboard system allows annotating and sharing by QR code.
Looping-out display available.
Various audio and video interfaces for device access.
Built-in network switch chip saves a network switch.
Built-in Android system provides kinds of applications.
Compatible with OPS/OPS-C devices, realizing smooth switch between built-in systems.
Ultra-thin design with an aluminum profile frame.


Specification


Product Model
DS-D5B86RB/D

Display

Screen Size
86 inch

Backlight
DLED

Pixel Pitch
0.164 (H) × 0.493 (V) mm

Resolution
3840 × 2160 @60 Hz

Brightness
350 cd/m² (Typ.)

Color Depth
10 bit

Contrast Ratio
5000:1

Response Time
6 ms

Color Gamut
90% NTSC (CIE1931) (Typ.)

Refresh Rate
60 Hz

Viewing Angle
178°(H)/178°(V)

Surface Haze
25% Haze

Display Area
1895.04mm × 1065.96mm

Working Duration
7 × 16 hours

Touch

Type
Infrared touch screen

Glass
AG smooth glass

Touch Point
Max 45 point multi-touch

Touch Response Time
＜ 10 ms

Touch Precision
±1 mm (≥ 90% touching area)

Built-In System

Operation System
Android 11

Processor
A72×2 + A53×4, 1.8 GHz

Memory
4 GB

Built-In Storage
64 GB

NIC
Built-in 1000 Mbps NIC, supporting routing; IEEE 802.11 a/b/g/n/ac with 2 × 2 MIMO

Camera

Pixel
8 MP

Camera Function
Smart switch between Android system and OPS

Field Angle
120°(diagonal), 110°(horizontal), 66°(vertical)

Distortion
≤6%

Camera Resolution Ratio
Up to 4K

Microphone

Specification
Omni-directional 6-array layout

Mic Function
Echo reduction and smart noise-cancellation

Voice Distance
8 m

Sampling Rate
32 K

Mic Sampling Rate
16 bit

Internal Function

Loudspeaker
Built-in 2 × 16 W loudspeaker

Bluetooth
Built-in BLE (Bluetooth Low Energy) module supports Bluetooth 5.0 and previous version

Interface

Video & Audio Input
HDMI IN × 2 (Max 4K @ 30 Hz), LINE IN × 1

Video & Audio Output
HDMI OUT (HDMI 2.0) × 1 (Max 4K @ 60 Hz), LINE OUT × 1

Control Interface
RS-232 × 1, Touch-USB × 1

Network Interface
RJ45 (1000 Mbps port) × 2

Data Transmission Interface
USB-C × 1, USB-A × 2 (front panel), USB-A × 2 (rear panel)

Power

Power Consumption
≤ 490 W (full load)

Standby Consumption
0.5 W

General

Power
100 to 240 VAC, 50/60 Hz

Product Dimensions
1963 × 1159 × 87.5 mm

Package Dimensions
2187 × 1366 × 274 mm

Net Weight
65.62 kg

Gross Weight
86.74 kg

Lifespan
50,000 hours

Accessories
2 pens, wall-mounted bracket included in the package

Working Environment

Working Temperature
0 ℃ to 40 ℃ (32 ℉ to 104 ℉)

Working Humidity
10% to 90% RH
