iiyama ProLite TF1215MC-B1 Open Frame Interactive Display, 12″ XGA IPS Display, Projective Capacitive Touch Technology, 10 Touch Points, 25ms (BtB) Response Time, Black | TF1215MC-B1

Description for iiyama ProLite TF1215MC-B1 Open Frame Interactive Display, 12″ XGA IPS Display, Projective Capacitive Touch Technology, 10 Touch Points, 25ms (BtB) Response Time, Black | TF1215MC-B1

ProLite TF1215MC-B1 12.1’’ PCAP 10pt touchscreen solution for pick-up pointsBuilt into a rugged, edge-to-edge glass bezel the ProLite TF1215MC-B1 guarantees high durability and scratch-resistance, making it perfect for high use public facing applications. Landscape, portrait and face-up orientation ensure flexibility in any type of installation. It can operate in temperatures ranging from -20˚C-to 60˚C and is IP65 rated, resulting in dust and water resistance from the front making it a reliable solution for pick-up points and kiosks. For ease of integration, the TF1215MC-B1 can be equipped with optional external mounting brackets (OMK3-1) making it an ideal solution for kiosk integrators, industrial environments, control rooms and interactive multimedia.  Specifications

DISPLAY CHARACTERISTICS


Design
Open Frame

Diagonal
12.1″, 31cm

Panel
IPS Technology

Native resolution
1024 x 768 (0.8 megapixel)

Aspect ratio
4:3

Panel brightness
540 cd/m²

Brightness
450 cd/m² with touch

Light transmittance
85%

Static contrast
1000:1

Response time (BTB)
25ms

Viewing zone
horizontal/vertical: 178°/178°, right/left: 89°/89°, up/down: 89°/89°

Colour support
16.2mln (6bit + Hi-FRC)

Horizontal Sync
31.4 – 60kHz

Viewable area W x H
245.8 x 184.3mm, 9.7 x 7.2″

Pixel pitch
0.24mm

Bezel colour and finish
black

TOUCH


Touch technology
projective capacitive

Touch points
10 (HID, only with supported OS)

Touch method
finger, glove (latex), capacitive stylus

Touch interface
USB

Supported operating systems
All iiyama monitors are Plug & Play and compatible with Windows and Linux. For details regarding the supported OS for the touch models, refer to the driver instruction file available in the downloads section.

Through-Glass
6mm

Palm rejection
yes

INTERFACES / CONNECTORS / CONTROLS


Analog signal input
VGA x1

Digital signal input
HDMI x1


DisplayPort x1

Audio output
Mini jack x1

HDCP
yes

FEATURES


Extra
anti-fingerprint coating, touch through-glass

Glass thickness
3.15mm

Glass hardness
7H

60950 Ball drop test
yes

Water and dust protection
IP65 (front)

Water tight seal
yes

OSD key lock
yes

GENERAL


OSD languages
EN, DE, FR, ES, IT, CN, JP

Control buttons
Menu, Scroll up / Brightness, Scroll down / Contrast, Select, Power

User controls
picture (contrast, brightness, H. position, V. position, phase, clock, auto adjust), advanced (colour temperature, sharpness), OSD (OSD timeout, OSD position, OSD H. position, OSD V. position, touch switch), option (reset, language, source select, display mode, factory)

Plug&Play
DDC2B

MECHANICAL


Orientation
landscape, portrait, face-up

VESA mounting
100 x 100mm

Operation temperature range (-°/+)
-20°C – 60°C

Storage temperature range
-20°C – 60°C

ACCESSORIES INCLUDED


Cables
power, USB, HDMI, DP

Guides
quick start guide, safety guide

Other
AC adapter, external control pad

Remote control
external control pad

POWER MANAGEMENT


Power supply unit
external

Power supply
DC 12 V

Power usage
10W typical, 0.55W stand by, 0.5W off mode

SUSTAINABILITY


Regulations
CE, EAC, RoHS support, ErP, WEEE, cULus, REACH

Energy efficiency class (Regulation (EU) 2017/1369)
F

DIMENSIONS / WEIGHT


Product dimensions W x H x D
308.5 x 248 x 41.5mm

Box dimensions W x H x D
435 x 355 x 165mm

Weight (without box)
2.1kg

Weight (with box)
3.9kg

EAN code
4948570118007
