iiyama ProLite TF2415MC-B2 Open Frame Interactive Display, 24″ FHD VA LED Display, Projective Capacitive Touch Technology, 10 Touch Points, 16ms (BtB) Response Time, Black | TF2415MC-B2

Apple Shopping Event

Hurry and get discounts on all Apple devices up to 20%

Sale_coupon_15

Compare

Add to wishlist

11 People watching this product now!

Payment Methods:

Description

Description for iiyama ProLite TF2415MC-B2 Open Frame Interactive Display, 24″ FHD VA LED Display, Projective Capacitive Touch Technology, 10 Touch Points, 16ms (BtB) Response Time, Black | TF2415MC-B2

ProLite TF2415MC-B2 Open Frame PCAP 10 point touch screen equipped with touch through glass functionThe ProLite TF2415MC-B2 (23.8 inch) uses PCAP touch technology and is built into an eye-catching bezel with edge-to-edge glass. Thanks to a glass overlay covering the screen and a rugged bezel, it guarantees high durability and scratch-resistance, making it perfect for kiosk and high use public facing applications. Equipped with a foam seal finish it supports seamless integration into kiosks and provides IP65 rating resulting in dust and water resistance from the front. Landscape, portrait and face-up orientation ensures flexible mounting possibilities in almost any installation. For ease of integration, the TF2415MC-B2 can be equipped with optional external mounting brackets (OMK2-1) making it an ideal solution for kiosk integrators, industrial environments, control rooms and interactive multimedia. Specifications

DISPLAY CHARACTERISTICS

Design
Open Frame

Diagonal
23.8″, 60.5cm

Panel
VA LED

Native resolution
1920 x 1080 (2.1 megapixel Full HD)

Aspect ratio
16:9

Panel brightness
350 cd/m²

Brightness
315 cd/m² with touch

Light transmittance
90%

Static contrast
3000:1

Response time (BTB)
16ms

Viewing zone
horizontal/vertical: 178°/178°, right/left: 89°/89°, up/down: 89°/89°

Horizontal Sync
31.4 – 82kHz

Viewable area W x H
527.04 x 296.46mm, 20.7 x 11.7″

Pixel pitch
0.2745mm

Bezel colour and finish
black

TOUCH

Touch technology
projective capacitive

Touch points
10 (HID, only with supported OS)

Touch method
stylus, finger, glove (latex)

Touch interface
USB

Supported operating systems
All iiyama monitors are Plug & Play and compatible with Windows and Linux. For details regarding the supported OS for the touch models, please refer to the driver instruction file available in the downloads section.

Through-Glass
6mm

INTERFACES / CONNECTORS / CONTROLS

Analog signal input
VGA x1

Digital signal input
HDMI x1

DisplayPort
x1

Audio output
Mini jack x1

HDCP
yes

FEATURES

Extra
anti-fingerprint coating, touch through-glass

Glass hardness
7H

60950 Ball drop test
yes

Water and dust protection
IP65 (front)

Water tight seal
yes

OSD key lock
yes

GENERAL

OSD languages
EN, DE, FR, ES, IT, CN, JP

Control buttons
Menu, Scroll up/ Brightness, Scroll down/ Contrast, Select, Power

User controls
picture (contrast, brightness, H. position, V. position, phase, clock, auto adjust), advanced (color temp., sharpness), OSD (timeout, position, H. position, V. position, touch switch), option (reset, language, source select, display mode, factory)

Plug&Play
DDC2B

MECHANICAL

Orientation
landscape, portrait, face-up

VESA mounting
100 x 100mm

Operation temperature range
0°C – 40°C

Storage temperature range
-20°C – 60°C

ACCESSORIES INCLUDED

Cables
power, USB, HDMI, DP

Guides
quick start guide, safety guide

Other
AC adapter, Touch Panel Driver Disk (CD-ROM), external control pad

POWER MANAGEMENT

Power supply unit
external

Power supply
DC 12 V

Power usage
24.4W typical, 1.06W stand by, 0.32W off mode

SUSTAINABILITY

Regulations
CB, CE, RoHS support, ErP, WEEE, CU, cULus, REACH

Energy efficiency class (Regulation (EU) 2017/1369)
F

REACH SVHC
above 0.1%: Lead

DIMENSIONS / WEIGHT

Product dimensions W x H x D
575 x 347 x 42.5mm

Weight (without box)
5.8kg

EAN code
4948570116775
