iiyama ProLite TF5539UHSC-W1AG Interactive Display, 55″ 4K UHD IPS LED Display, 60Hz Refresh Rate, 8ms (GtG) Response Time, Projective Capacitive, 6mm Through Glass, White | TF5539UHSC-W1AG

IPS Technology

Touch Though-Glass

Touch Technology – Capacitive

Anti-Glare Coating

24/7 Operation

Apple Shopping Event

Hurry and get discounts on all Apple devices up to 20%

Sale_coupon_15

Compare

Add to wishlist

16 People watching this product now!

Payment Methods:

Description

Description for iiyama ProLite TF5539UHSC-W1AG Interactive Display, 55″ 4K UHD IPS LED Display, 60Hz Refresh Rate, 8ms (GtG) Response Time, Projective Capacitive, 6mm Through Glass, White | TF5539UHSC-W1AG

ProLite TF5539UHSC-W1AG 55″ Open Frame PCAP interactive large format display with 15pt touch capability, IPS panel technology and touch through glass function for landscape, portrait or face up useThe 4K UHD (3840×2160) Open Frame TF5539UHSC-W1AG with Touch-Through-Glass function guarantees a seamless and accurate touch response for true kiosk integration or interactive behind-glass-retail applications. The IPS panel technology offers exceptional colour performance and wide viewing angles, making it a perfect solution for interactive shop windows, education, kiosks and in-store communications. Featuring a metal housing with 60950-1 ball-drop proof, scratch-resistant and edge-to-edge glass, this display can be installed in the most demanding environments for an 24/7 usage and in different set-ups as a result of its Open Frame side mounting holes. For ease of integration, the TF5539UHSC-W1AG can be equipped with optional external mounting brackets (OMK4-2) making it an ideal solution for kiosk integrators and interactive multimedia. Specifications

DISPLAY CHARACTERISTICS

Design
Edge to edge glass, Open Frame

Diagonal
55″, 139cm

Panel
IPS LED, AG coated glass

Native resolution
3840 x 2160 @60Hz (8.3 megapixel 4K UHD)

Aspect ratio
16:9

Panel brightness
500 cd/m²

Light transmittance
84%

Static contrast
1100:1

Response time (GTG)
8ms

Viewing zone
Horizontal/Vertical: 178°/178°, Right/Left: 89°/89°, Up/Down: 89°/89°

Colour support
16.7mln 8bit

Horizontal Sync
30 – 83kHz

Viewable area W x H
1212 x 683mm, 47.7 x 26.89″

Bezel width (sides, top, bottom)
29.7mm, 33.2mm, 33.2mm

Pixel pitch
0.315mm

Bezel colour and finish
White, matte

TOUCH

Touch technology
Projective capacitive

Touch points
15 (HID, only with supported OS)

Touch accuracy
+- 3mm

Touch method
Stylus, finger, glove (latex)

Touch interface
USB

Supported operating systems
All iiyama monitors are Plug & Play and compatible with Windows and Linux. For details regarding the supported OS for the touch models, please refer to the driver instruction file available in the downloads section.

Through-Glass
6mm

Palm rejection
Yes

INTERFACES / CONNECTORS / CONTROLS

Analog signal input
VGA x1 (max. 1920×1080 @60Hz)

Digital signal input
HDMI x2 (v.2.0 x1 max. 3840×2160 @60Hz, v.1.4 x1 max. 3840×2160 @30Hz)

DisplayPort x1
(v.1.2 max. 3840×2160 @60Hz)

Audio input
Mini jack x1

Monitor control input
RS-232c x1

RJ45 (LAN) x1

Audio output
Mini jack x1

Speakers
2 x 8W

HDCP
Yes

FEATURES

Extra
Handles, touch through-glass, temperature sensor with fan control

Max. non-stop operating time
24/7

Anti image retention
Yes

Glass thickness
4mm

Glass hardness
7H

60950 Ball drop test
Yes

Water and dust protection
IP54 (front)

Housing (bezel)
Metal

GENERAL

OSD languages
EN, DE, FR, ES, IT, RU, NL, PL

Control buttons
Power, menu, exit, up, down

User controls
Picture (backlight, contrast, brightness, sharpness, H/V-position, phase, Chroma, adjust screen, colour temp., picture mode), sound (treble, bass, balance, volume, mute, speaker, audio source), screen (aspect, Touch feature, reset), settings (OSD time, OSD H/V position, language, schedule, power save, control setting, network setting, advanced, information, all reset)

Plug&Play
DDC2B

MECHANICAL

Orientation
Landscape, portrait, face-up

VESA mounting
600 x 400mm

Operation temperature range
0°C – 40°C

Storage temperature range
-20°C – 60°C

MTBF
50000 hours (excluding backlight)

ACCESSORIES INCLUDED

Cables
Power, USB, HDMI, DP

Guides
Quick start guide, safety guide

Cable cover
Yes

POWER MANAGEMENT

Power supply unit
Internal

Power supply
AC 100 – 240V, 50/60Hz

Power usage
155W typical, 1.5W stand by, 0.3W off mode

SUSTAINABILITY

Regulations
CE, EAC, RoHS support, ErP, WEEE, cULus, REACH, UKCA

Energy efficiency class (Regulation (EU) 2017/1369)
G

REACH SVHC
Above 0.1%: Lead

DIMENSIONS / WEIGHT

Product dimensions W x H x D
1271.5 x 749.4 x 68mm

Box dimensions W x H x D
1400 x 930 x 245mm

Pallet volume
10pcs

Pallet dimensions W x H x D
1420 x 1245 x 1986mm

Weight (without box)
41kg

Weight (with box)
46.5kg

EAN code
4948570118076
