iiyama ProLite TW1023ASC-B1P Interactive Display, 10″ WXGA IPS LED Display, 60Hz Refresh Rate, 25ms (GtG) Response Time, Projective Capacitive Touch, 10 Touch Points, Black | TW1023ASC-B1P

Description for iiyama ProLite TW1023ASC-B1P Interactive Display, 10″ WXGA IPS LED Display, 60Hz Refresh Rate, 25ms (GtG) Response Time, Projective Capacitive Touch, 10 Touch Points, Black | TW1023ASC-B1P

ProLite TW1023ASC-B1P 10.1” PCAP 10pt touch screen with Android and Power over Ethernet TechnologyThe ProLite TW1023ASC-B1P touch panel PC is a perfect choice for high-use environments such as retail, interactive POS, information desks or hospitality applications. Thanks to the pre-installed Android operating system, it is possible to easily customize the monitor by installing applications directly to it.The Power over Ethernet technology (POE) allows to provide both data connection and power by a single cable, simplifying all installations. This monitor can operate in landscape, portrait or face-up orientation. Together with the built-in camera, microphone and speakers it offers limitless, interactive installation possibilities.  Specifications

DISPLAY CHARACTERISTICS


Design
Edge to edge glass

Diagonal
10.1″, 25.5cm

Panel
IPS Panel Technology, LED

Native resolution
1280 x 800 (1 megapixel HD)

Aspect ratio
16:10

Panel brightness
450 cd/m²

Brightness (with touch)
385 cd/m²

Light transmittance
85%

Static contrast (with touch)
1000:1

Response time (GTG)
25ms

Viewing zone
horizontal/vertical: 160°/160°, right/left: 80°/80°, up/down: 80°/80°

Colour support
16.7mln 8bit

Viewable area W x H
216.6 x 135.4mm, 8.5 x 5.3″

Pixel pitch
0.1692mm

Bezel colour and finish
black, matte

TOUCH


Touch technology
projective capacitive

Touch points
10

Touch method
finger, glove (latex), capacitive stylus

Touch interface
USB

INTERFACES / CONNECTORS / CONTROLS


Digital signal output
HDMI x1 (mini HDMI, 1280×720 @60Hz)

Audio output
Speakers 2 x 1.5W

USB ports
x2 (2.0, 1 x MICRO with OTG)

RJ45 (LAN)
x1 (PoE – IEEE802.3af/15.4W)

Microphone
1

FEATURES


Integrated software
Android 11

CPU
Rockchip RK3288, quad-core Cortex-A17 up to 1.8GHz

GPU
Quad-core Cortex A17

Storage
16GB eMMC

Memory
2GB DDR3

WiFi
IEEE802.11b/g/n

Bluetooth
4.0

Extra
auto-rotation, webcam (2 megapixel), microphone, SD card slot, anti-fingerprint coating

Max. non-stop operating time
24/7

Glass thickness
1.25mm

Glass hardness
7H

GENERAL


Applications
Install/manage applications, calculator, calendar, camera, chrome, alarm/clock/timer/stopwatch, email, manage files/folders/images/video/audio, organize albums, power management, play audio/video files, search engine, system preferences, sound recorder

MECHANICAL


Orientation
landscape, portrait, face-up

VESA mounting
75 x 75mm

ACCESSORIES INCLUDED


Guides
quick start guide, safety guide

Other
AC adapter

Cable cover
yes

POWER MANAGEMENT


Power supply unit
external

Power supply
DC 12 V

Power usage
7W typical

SUSTAINABILITY


Regulations
CE, RoHS support, ErP, WEEE, REACH

REACH SVHC
above 0.1%: Lead

DIMENSIONS / WEIGHT


Product dimensions W x H x D
255 x 172 x 30.5mm

Box dimensions W x H x D
398 x 223 x 68mm

Pallet volume
256pcs

Pallet dimensions W x H x D
1000 x 1200 x 2150mm

Weight (without box)
0.8kg

Weight (with box)
1.36kg

EAN code
4948570117116
