UniView 86” Smart Ultra-Narrow Interactive Display, 4K UHD Resolution, Infrared Touch Screen, 8ms Response Time, Android 12, 8GB RAM & 64GB eMMC, 2 Touch Pens, Free VESA Mount | MW3586-U-E
Description for UniView 86” Smart Ultra-Narrow Interactive Display, 4K UHD Resolution, Infrared Touch Screen, 8ms Response Time, Android 12, 8GB RAM & 64GB eMMC, 2 Touch Pens, Free VESA Mount | MW3586-U-E
MW3586-U-E Key Features
4K UHD anti-glare display delivers images with extreme detail.
Zero bonding technology between lcd panel and cover glass brings brighter viewing and smoother touching experience.
Ultra-narrow and equal-width bezel design for perfect aesthetics.
Minimalist geometric line design and smooth border outline, elegant and attractive.
Dual Wi-Fi modules with both Wi-Fi and hotspot support.
Dual-channel, 6-array speaker brings high-quality surround sound.
High-precision infrared touch technology allows up to 20-point touch, realizing smooth co-authoring.
Bluetooth 5.2 offers higher data transmission rate, and lower power consumption.
4K UI, mobile-level operation, just like use a mobile phone.
A variety of quick tools, such as annotation, screenshot, etc., improve usability and interaction efficiency.
Wireless screen mirroring from various operating systems such as Android, iOS and Windows to the display with one touch.
Fast file transfer. Allows users to quickly transfer files to the display via a QR code.
OTA remote upgrade. The system can be upgraded online without backing up data.
Specifications
Panel
Backlight
DLED backlight
Panel size
86 inches
Resolution
3840*2160
Brightness (cd/m²)
350
Contrast Ratio
1200:1
Response Time (ms)
8
Color Support
1.07B
Viewing Angle (H/V)
178°/178°
System
CPU
RK3588: 4-core A76 (2.4G) + 4-core A55 (1.8G)
CPU Frequency
2.4GHz
RAM/ROM
DDR4: 8GB eMMC: 64GB
System Compatibility
Android 12.0
Touch
Touch Control
Infrared touch screen, 20-point multi-touch at most
Touch Precision (mm)
±1
Recognizable Object
5 points 2mm
Glass
4mm tempered glass, level 7 on Mohs hardness scale, anti-glare
Touch Response Time (ms)
≤10
Touchscreen Input
Opaque objects (e.g. finger, pen, etc.)
Interface
Video Input
3*HDMI IN (4K@60)
Video Output
1*HDMI OUT (4K@60)
Audio Input
1*AUDIO IN
Audio Output
1*AUDIO OUT
Other Interfaces
1*RS232、3* USB 3.0、1* USB Type C、1* USB Type B
Network
2*RJ 45,10M/100M/1000M adaptive Ethernet Interfaces
Audio
Frequency domain
80Hz～20kHz
Speaker
Left channel 17W: 1*treble (8Ω 5W) + 2*bass (4Ω 6W)
Right channel 17W: 1*treble (8Ω 5W) + 2*bass (4Ω 6W)
Wi-Fi
WiFi Configuration
Wi-Fi6 + Wi-Fi5 dual-module, supports 5G/2.4G
WiFi Performance
30 m² coverage, 20m transmission distance in open space
Bluetooth
Bluetooth Version
5.2
Bluetooth Performance
10m transmission distance in open space
VESA
Description
Wall mount hole (mm)
800*400
Wall mount screw
4-M8 screw hole
General
Power Supply
AC 100 to 240V, 50/60Hz
Overall Power Consumption （W）
≤365 (on without OPS)
Standby Power Consumption （W）
＜0.5
Product Dimensions （W*H*D）（mm）
1967*1173*89
Package Dimensions （W*H*D）（mm）
2117*1336*247
Weight（Kg）
Net weight: 68.0
Gross weight:79.2
Operating Temperature
0 to 50°C
Operating Humidity
10% to 90% (non-condensing)
Storage temperature
-20 to 60°C
Storage humidity
0% to 95% (non-condensing)
Accessories Included
1*power cord、2*touch pen、1*quick guide
Free Delivery
We offer express delivery to Dubai, Abu Dhabi, Al Ain, Sharjah, Ajman, Ras Al Khaimah, Fujairah, Umm Al Quwain, UAE for UniView 86” Smart Ultra-Narrow Interactive Display, 4K UHD Resolution, Infrared Touch Screen, 8ms Response Time, Android 12, 8GB RAM & 64GB eMMC, 2 Touch Pens, Free VESA Mount | MW3586-U-E.
Best Price Guarantee
We offer the best price for UniView 86” Smart Ultra-Narrow Interactive Display, 4K UHD Resolution, Infrared Touch Screen, 8ms Response Time, Android 12, 8GB RAM & 64GB eMMC, 2 Touch Pens, Free VESA Mount | MW3586-U-E in Dubai, UAE. Buy now with the best price!
Read More
Specifications for UniView 86” Smart Ultra-Narrow Interactive Display, 4K UHD Resolution, Infrared Touch Screen, 8ms Response Time, Android 12, 8GB RAM & 64GB eMMC, 2 Touch Pens, Free VESA Mount | MW3586-U-E
General
Brand
Uniview
Model
MW3586-U-E
Microless SKU
173718
Date first available
19 March, 2024
Shipping Weight
79.20 Kg
Shipping Dimensions
211.70 cm x 24.70 cm x 133.60 cm
