ViewBoard IFP7550-5 ViewBoard 75″ 4K UHD IPS Interactive Display, 8m Resp Time, Dual-pen & Ultra Fine Touch, TFT LCD Module, 4GB+ 32GB , HDMI/USB -C /Wi-Fi M Slot, Free VESA Mount, Black | IFP7550-5

Description for ViewBoard IFP7550-5 ViewBoard 75″ 4K UHD IPS Interactive Display, 8m Resp Time, Dual-pen & Ultra Fine Touch, TFT LCD Module, 4GB+ 32GB , HDMI/USB -C /Wi-Fi M Slot, Free VESA Mount, Black | IFP7550-5

Designed with modern educators in mind, the ViewBoard® 50-5 Series offers an intuitive and interactive interface for a multi-user writing experience. With a single-cable USB-C for instant, worry-free connectivity, teachers can seamlessly plug-in and control their devices while continuing the lesson. Both students and educators enjoy smooth writing with Ultra Fine Touch Technology offering 40-point touch, and the dual-pen that comes in a range of colors and sizes. Rest assured you and your students’ eyes are cared for and protected as the ViewBoard® 50-5 Series comes with Flicker-Free technology and an integrated TÜV certified blue light filter for all brightness levels. Fully integrated with the myViewBoard suite, the ViewBoard® 50-5 Series brings together hardware and software for a complete classroom solution. Compatible with a full line of accessories, the ViewBoard® 50-5 Series enables you to effectively teach with a variety of engaging tools.



SPECIFICATIONS

Display
Panel Size: 75″
Panel Type: TFT LCD Module with DLED Backlight. IPS
Display Area (mm): 1650.24(H) × 928.26(V)
Aspect Ratio: 16:9
Resolution: UHD 3840×2160
Colors: 1.07B colors (10bit)
Brightness: 400 nits (typ.)
Contrast Ratio: 1200:1 (typ.) 5000:1 (DCR)
Response Time: 8ms
Viewing Angles: H = 178, V = 178 typ.
Backlight Life: 50,000 hours(Min)
Surface Treatment: Hardness: 7H, Anti-glare coating
Bezel: Slim
Orientation: Landscape

Platform
Processor: ARM Cortex-A73*4 + Cortex-A53*4
RAM: 4GB
Storage: 32GB

Touch
Type/ Tech: Ultra Fine Touch Techology (IR Recognition)
Touch Resolution: 32768 ×32768
Touch Point: Windows: 40 points of touch, Android : 20 points of touch

INPUT
HDMI: 2.0 x 3 (3840×2160 @60Hz, HDCP2.2, HDMI1 with CEC/ARC)
RS232: x1
OPS: x1
WiFi: x 1 module slot

OUTPUT
HDMI: x1 (4K@60Hz)
Audio: x1 (Earphone out)
SPDIF: x1 (optical)

LAN
RJ45: x2

USB
Type A: 2.0 x 2
3.0 x 4
Type B: x2, for touch
Type C: x1 ( DP 1.2, USB2.0, PD65W, Ethernet 100M)

SPEAKERS
12W x 2 + 16W x 1 subwoofers

Top Camera Plate
Yes

Embedded OS
Android 11

Bundle Software
Basic Annotation Software: myViewBoard
Pro Annotation Software: myViewBoard for Windows (Embedded in Windows Slot-in PC)
Wireless Presentation: vCast/myViewBoard Display App

Special Features
All-in-one USB port: “SmartPort™ USB” to all channels.
Simple LAN sharing between IFP and slot-in device: Yes
Light Sensor: Yes

Power
Voltage: 100-240VAC +/- 10% Wide Range
Consumption: 135W(typ.), 0.5W (off)

ERGONOMICS
Wall Mount (VESA® ): 800 mm x 400 mm

OPERATING CONDITIONS
Temperature (º C): 0°C to 40°C
Humidity: 10% ~ 90% RH non-condensing

DIMENSIONS (W x H x D)
Physical (inch / mm): 67.3 x 40.2 x 3.5 in / 1710 x 1020 x 90 mm
Packaging (inch / mm): 76.0 x 44.9 x 11.0 in / 1930 x 1140 x 280 mm

WEIGHT
Net (lb / kg): 118.8lb/53.9kg
Gross (lb / kg): 158.5lb/71.9kg

REGULATIONS
cTUVus, FCC/ICES003, Energy Star 8.0, EMC/CE, CB/LVD, GOST-R/EAC, UkrSEPRO, EPEAT, Mexico NOM , Mexico Energy, UKCA, UK-EEL, BSMI, BIS, LBL( Low Blue Light Certification), Flicker Free, Green BOM, RoHS, ErP-Eco, REACH, SCIP, WEEE, TPCH , Packing waste, CA65, PAIA

PACKAGE CONTENTS
1. Power cord
2. Remote control with AAA battery
3. Touch USB cable
4. Touch pen x 2
(VB-PEN-009)
5. Quick Start Guide + Compliance statement
6. RS232 adapter
7. Clamp x 5
8. Camera Plate
9. Screw x 8
10. HDMI cable

Compatible Slot-in PC
• VPC2-O series
• VPC2-O-B series
• VPC25-W33-O1-1B
• VPC27-W53-O1-1B
• VPC12-WPO-17
• VPC12-WPO-18

Free Delivery

We offer express delivery to Dubai, Abu Dhabi, Al Ain, Sharjah, Ajman, Ras Al Khaimah, Fujairah, Umm Al Quwain, UAE for ViewBoard IFP7550-5 ViewBoard 75″ 4K UHD IPS Interactive Display, 8m Resp Time, Dual-pen & Ultra Fine Touch, TFT LCD Module, 4GB+ 32GB , HDMI/USB -C /Wi-Fi M Slot, Free VESA Mount, Black | IFP7550-5.

Best Price Guarantee

We offer the best price for ViewBoard IFP7550-5 ViewBoard 75″ 4K UHD IPS Interactive Display, 8m Resp Time, Dual-pen & Ultra Fine Touch, TFT LCD Module, 4GB+ 32GB , HDMI/USB -C /Wi-Fi M Slot, Free VESA Mount, Black | IFP7550-5 in Dubai, UAE. Buy now with the best price!

Read More

Specifications for ViewBoard IFP7550-5 ViewBoard 75″ 4K UHD IPS Interactive Display, 8m Resp Time, Dual-pen & Ultra Fine Touch, TFT LCD Module, 4GB+ 32GB , HDMI/USB -C /Wi-Fi M Slot, Free VESA Mount, Black | IFP7550-5

General

Brand

Viewsonic

Model

IFP7550-5

Microless SKU

120079

Date first available

08 May, 2023

Shipping Weight

71.00 Kg

Shipping Dimensions

114.00 cm x 193.00 cm x 28.00 cm
