ViewSonic IFP8630 ViewBoard Interactive Monitor, 86″ TFT LCD Display, 60Hz Refresh Rate, 8ms Response Time, Cortex-A73 CPU, 3GB DDR4 RAM, 16GB Storage, IR Recognition Touch, Free VESA Mount | IFP8630

Description for ViewSonic IFP8630 ViewBoard Interactive Monitor, 86″ TFT LCD Display, 60Hz Refresh Rate, 8ms Response Time, Cortex-A73 CPU, 3GB DDR4 RAM, 16GB Storage, IR Recognition Touch, Free VESA Mount | IFP8630

Features
UFT (Ultra Fine Touch) Technology

myViewBoard® digital whiteboard software

Dual-pen writing with 3mm/8mm diameter pen tips

Ambient Light Sensor

Wireless presentation across devices
OVERVIEWThe ViewBoard® IFP30 series embraces ultra fine touch technology to offer fine precision writing. It increases the writing accuracy with 2mm height sensitivity while allowing for dual-pen writing with both 3mm & 8mm diameter pens. It’s also very responsive to distinguish the touch diameters among pens, fingers and palms to avoid false strokes. In addition, the IFP30 series is integrated with myViewBoard® whiteboarding software to provide more accommodative features such as to collaboration on the go; and it’s further complimented by native casting including Miracast, Airplay, and Chromecast; as well as the front I/O ports including HDMI, Touch USB, and USB for easy access. Interactive whiteboards are becoming commonplace. The IFP30 series is the solution for schools and workplaces of all sizes and considerations. Specifications

Display

Panel Size
86″

Type/Tech
TFT LCD module with DLED backlight

Display Area (mm)
1895.04 x 1065.94

Aspect Ratio
16:9

Native Resolution
4K @ 60Hz

Colors
10 bits

Brightness
400 cd/m² (Typ.)

Contrast Ratio
1200:1

Response Time
8ms (Type)

Viewing Angles
Horizontal = 178°, Vertical = 178° (typ.)

Backlight Life
30,000 hours (min)

Surface Treatment
Hardness: 7H, Coating: AG coating

Bezel
Slim

Orientation
Landscape

Platform

Processor
Cortex-A732 + Cortex-A532 1.5Hz

RAM
3GB DDR4

Storage
16GB

Touch

Type/ Tech
IR Recognition

Touch Resolution
32767W x 32767D

Touch Point
20 points, 5 writing

Input

HDMI
Front: 1, Rear: 2 (all ports HDMI 2.0)

RGB / VGA
1

DisplayPort
DP1.2: 1

Audio
PC audio in (3.5 mm): 1

RS232
1

OPS
1

Output

HDMI
1 (up to 4K @ 60Hz)

Audio
3.5mm Earphone Out: 1, SPDIF: 1 (optical)

LAN
RJ45: 2, 10M/100M

USB

Type A
USB 2.0: 4 (Front: 2, Rear: 2)

Type B
For touch: Front: 1, Rear: 1

Speakers

Speakers
15W x 2

Top Camera Plate
Yes

Compatibility

RGB PC/HDMI PC
VGA: 1080p, HDMI: 4K

HDMI
3840×2160

DisplayPort
3840×2160

Embedded OS
Android 8.0

Bundle Software

Basic Annotation Software
myViewBoard for Android

Pro Annotation Software
myViewBoard for Windows (embedded in VPC12)

Wireless Presentation
Viewboard Cast: Yes

ViewSonic Launcher
Embedded

Special Features

All-in-one USB port
Front “SmartPort USB” to all channels

LAN Sharing
10M/100M share to OPS

Power

Voltage
PB model: 100-240VAC +/- 10% Wide Range

Ergonomics

Wall Mount (VESA®)
400 x 700 mm

Operating Conditions

Temperature
0°C to 40°C

Humidity
20% to 80% RH Non-Condensing (working)

Dimensions (W x H x D)

Physical (inch / mm)
2006.4 x 1189.1 x 118 (mm), 79 x 46.8 x 4.7 (inch)

Packaging (inch / mm)
2140 x 1340 x 280 (mm), 84.3 x 52.8 x 11 (inch)

Weight

Net (lb / kg)
176 lb / 79.8 kg

Gross (lb / kg)
219.4 lb / 99.5 kg

Regulations

Compliance
EMC/CE-EU, CB-EU/IEC62368, RoHS Green BOM & RoSH DoC, REACH, WEEE (Doc & Disassembly report), ErP, EAC (local apply), UKrSEPRO (local apply), RCM

ProAV Certificate Readiness

Crestron
On-going

Extron
On-going

AMX
Self-certificate

Compatible Slot-in PC
VPC12 series

Free Delivery

We offer express delivery to Dubai, Abu Dhabi, Al Ain, Sharjah, Ajman, Ras Al Khaimah, Fujairah, Umm Al Quwain, UAE for ViewSonic IFP8630 ViewBoard Interactive Monitor, 86″ TFT LCD Display, 60Hz Refresh Rate, 8ms Response Time, Cortex-A73 CPU, 3GB DDR4 RAM, 16GB Storage, IR Recognition Touch, Free VESA Mount | IFP8630.

Best Price Guarantee

We offer the best price for ViewSonic IFP8630 ViewBoard Interactive Monitor, 86″ TFT LCD Display, 60Hz Refresh Rate, 8ms Response Time, Cortex-A73 CPU, 3GB DDR4 RAM, 16GB Storage, IR Recognition Touch, Free VESA Mount | IFP8630 in Dubai, UAE. Buy now with the best price!

Read More

Specifications for ViewSonic IFP8630 ViewBoard Interactive Monitor, 86″ TFT LCD Display, 60Hz Refresh Rate, 8ms Response Time, Cortex-A73 CPU, 3GB DDR4 RAM, 16GB Storage, IR Recognition Touch, Free VESA Mount | IFP8630

General

Brand

Viewsonic

Model

IFP8630

Microless SKU

122326

Date first available

21 June, 2023

Shipping Weight

99.50 Kg

Shipping Dimensions

134.00 cm x 214.00 cm x 28.00 cm
