TP-Link TL-SG1005LP 5-Port Gigabit Desktop with 4-Port PoE+

Switch

TP-Link TL-SG1005LP 5-Port Gigabit Desktop with 4-Port PoE+ Switch

Dedicated 4-Port PoE+ Switch (40 W Budget) for Numerous Applications

TP-Link TL-SG1005LP 5-Port Gigabit Desktop with 4-Port PoE+ Switch

Compliance with the 802.3af/at PoE+ standard supports up to 30 W on each PoE port.

The total 40 W PoE power budget * for the 4× PoE ports opens up a wide range of applications, such as surveillance for offices, dormitories, and small businesses.

It is fully compatible with IP cameras, access points, IP phones, computers, printers, and more.

Intelligent Power Management

When total power consumption exceeds 40 W, the intelligent power management will cut the lower priority port power.

This ensures the high priority port’s power supply and protects the device from power overload.

It also automatically detects and provides the required power for your PoE devices while protecting your PoE and non-PoE equipment from being damaged.

Durable Metal Casing

The interior components of TL-SG1005LP are protected by high-quality metal casing to ensure a long product life.

Having passed an array of stringent reliability tests, TL-SG1005LP delivers switching performance you can depend on.

Core Features & Specs

• 5× Gigabit RJ‑45 ports (10/100/1000 Mbps), with 4 PoE+ ports (ports 1–4) supporting IEEE 802.3af/at (up to 30 W each), and a total PoE budget of 40 W

• Switching capacity: 10 Gbps, forwarding rate approx. 7.44 Mpps

• Advanced traffic control: 802.1p/DSCP QoS, IGMP snooping, IEEE 802.3x flow control.

• Fanless metal housing, desktop or wall-mount, plug-and-play with auto MDIX

• Extend Mode enables data + power up to 250 m at reduced 10 Mbps speeds

• PoE Auto Recovery restarts unresponsive devices automatically

• Intelligent power management: prioritizes ports 1–4 and cuts power to the lowest-priority port if demand > 40 W
